69
MIDI Implementation
Appendices
❍ Panpot (Controller number 10)
status 2nd byte 3rd byte
BnH 0AH vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Panpot: 00H - 40H - 7FH (left - center - right)
* Adjust the stereo location over 128 steps, where 0 is far left, 64 is center, and 127 is far
right. However this is not received when the Pan Control Switch is OFF.
❍ Expression (Controller number 11)
status 2nd byte 3rd byte
BnH 0BH vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Expression: 00H - 7FH (0 - 127)
* If the Volume Control Source (SYSTEM) is set to VOL&EXP, the volume of the Part
corresponding to the MIDI channel of the received message will be adjusted. However
this is not received if the Receive Volume (PATCH) is OFF.
* In GM mode, the volume can always be controlled.
❍ Hold 1 (Controller number 64)
status 2nd byte 3rd byte
BnH 40H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127) 0-63=OFF, 64-127=ON
* Not received when the Receive Hold-1 (PATCH) is OFF.
❍ Portamento (Controller number 65)
status 2nd byte 3rd byte
BnH 41H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127) 0-63=OFF, 64-127=ON
* The Portamento Sw (PATCH) will change.
❍ Sostenuto (Controller number 66)
status 2nd byte 3rd byte
BnH 42H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127) 0-63=OFF, 64-127=ON
❍ Soft (Controller number 67)
status 2nd byte 3rd byte
BnH 43H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127) 0-63=OFF, 64-127=ON
❍ Hold 2 (Controller number 69)
status 2nd byte 3rd byte
BnH 45H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127)
* A hold movement isn't done.
❍ Sound Controller 2 (Controller number 71)
status 2nd byte 3rd byte
BnH 47H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* The Resonance (PATCH) will change relatively.
❍ Sound Controller 3 (Controller number 72)
status 2nd byte 3rd byte
BnH 48H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* The Filter Envelope Time 2–4 (PATCH), Level Envelope Time 2–4 (PATCH) will change
relatively.
❍ Sound Controller 4 (Controller number 73)
status 2nd byte 3rd byte
BnH 49H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* The Filter Envelope Time 1 (PATCH), The Level Envelope Time 1 (PATCH) will change
relatively.
❍ Sound Controller 5 (Controller number 74)
status 2nd byte 3rd byte
BnH 4AH vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-64 - 0 - +63)
* The Cutoff Frequency (PATCH) will change relatively.
❍ General Purpose Controller 5 (Controller number 80)
status 2nd byte 3rd byte
BnH 50H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* Level Envelope Level 1–3 (PATCH) of Tone 1 will change relatively.
❍ General Purpose Controller 6 (Controller number 81)
status 2nd byte 3rd byte
BnH 51H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* Level Envelope Level 1–3 (PATCH) of Tone 2 will change relatively.
❍ General Purpose Controller 7 (Controller number 82)
status 2nd byte 3rd byte
BnH 52H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* Level Envelope Level 1–3 (PATCH) of Tone 3 will change relatively.
❍ General Purpose Controller 8 (Controller number 83)
status 2nd byte 3rd byte
BnH 53H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 40H - 7FH (-128 - 0 - +126)
* Level Envelope Level 1–3 (PATCH) of Tone 4 will change relatively.
❍ Portamento Control (Controller number 84)
status 2nd byte 3rd byte
BnH 54H kkH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
kk=source note number: 00H - 7FH (0 - 127)
* A Note On message received immediately after a Portamento control will be sounded
with the pitch changing smoothly from the source note number. If a voice is already
sounding at the same note number as the source note number, that voice will change
pitch to the pitch of the newly received Note On, and continue sounding (i.e., will be
played legato).
* The speed of the pitch change caused by Portamento is determined by the Portamento
Time value.
❍ Effect 1 (Reverb Send Level) (Controller number 91)
status 2nd byte 3rd byte
BnH 5BH vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Reverb Send Level: 00H - 7FH (0 - 127)
* In Performance mode, the Reverb Send Level parameter of each Part will change.
