15
Getting Ready to Play
Quick Start
Installing a Wave Expansion Board
One Wave Expansion Board (SR-JV80 series; sold separately) can be
installed in the JV-1010.
Waveform data, patches and rhythm sets are stored on the Wave Expansion
Board, so you can increase the number of available sounds by installing the
board in the JV-1010.
The Wave Expansion Board can be installed by removing the top cover.
■ How to Install a Wave Expansion Board
First, here are some important points to remember when installing into the
JV-1010:
● To avoid the risk of damage to internal components that can be caused by
static electricity, please carefully observe the following whenever you
handle the board.
• Before you touch the board, always first grasp a metal object (such as
a water pipe), so you are sure that any static electricity you might
have been carrying has been discharged.
• When handling the board, grasp it only by its edges. Avoid touching
any of the electronic components or connectors.
• Save the bag in which the board was originally shipped, and put the
board back into it whenever you need to store or transport it.
● Do not touch any of the printed circuit pathways or connection terminals.
● Never use excessive force when installing a circuit board. If it doesn’t fit
properly on the first attempt, remove the board and try again.
● When circuit board installation is complete, double-check your work.
● Install only the specified board, and remove only the specified screws.
● Be careful not to cut your hands on the opening for installing the board.
Installing a Wave
Expansion Board increases
the patches and drum sets
for Parts, but the number of
Parts doesn’t change.
