Getting Ready to Play
Making the Connections
The JV-1010 does not have a built-in amp or speakers. In order to produce
sound, you need to hook up audio equipment such as a monitor speaker or
a stereo set, or use headphones.
fig.1-06.e
Monitor speakers
(powered)
Stereo set etc.
Power amp
Mixer etc.
Cassette radio
MIDI keyboard
MIDI sequencer etc.
MIDI IN
MIDI OUT
MIDI OUT
DC IN
AC adaptor
Headphones
COMPUTER connector
