CHAPTER 17 SERIAL INTERFACE CHANNEL 0 (
µ
PD78078 SUBSERIES)
Figure 17-22. ACKT Operation
Caution Do not set ACKT before termination of transfer.
SCK0
6
SB0 (SB1)
ACKT
7
8
9
D2
D1
D0
ACK
When set during
this period
ACK signal is output for
a period of one clock
just after setting
