CHAPTER 11 WATCH TIMER
11.1 Watch Timer Functions
The watch timer has the following functions.
• Watch timer
• Interval timer
The watch timer and the interval timer can be used simultaneously.
(1) Watch timer
When the 32.768-kHz subsystem clock is used, a flag (WTIF) is set at 0.5-second or 0.25-second intervals.
When the 4.19-MHz (standard: 4.194304 MHz) main system clock is used, a flag (WTIF) is set at 0.5-second
or 0.25-second intervals.
Caution 0.5-second intervals cannot be generated with the 5.0-MHz main system clock. You should
switch to the 32.768 kHz subsystem clock to generate 0.5-second intervals.
(2) Interval timer
Interrupt requests (INTTM3) are generated at the preset time interval.
Table 11-1. Interval Timer Interval Time
When operated at
When operated at
When operated at
f
XX
= 5.0 MHz
f
XX
= 4.19 MHz
f
XT
= 32.768 kHz
2
4
x 1/f
W
410
µ
s
488
µ
s
488
µ
s
2
5
x 1/f
W
819
µ
s
977
µ
s
977
µ
s
2
6
x 1/f
W
1.64 ms
1.95 ms
1.95 ms
2
7
x 1/f
W
3.28 ms
3.91 ms
3.91 ms
2
8
x 1/f
W
6.55 ms
7.81 ms
7.81 ms
2
9
x 1/f
W
13.1 ms
15.6 ms
15.6 ms
f
XX
: Main system clock frequency (f
X
or f
X
/2)
f
X
: Main system clock oscillation frequency
f
XT
: Subsystem clock oscillation frequency
f
W
: Watch timer clock frequency (f
XX
/2
7
or f
XT
)
Interval Time
