68-Pin Telco pinout 93
Model 3196RC T-DAC User Manual B • WAN Network Module
Port 5/RX 10 10
44 Tan/Brown
Brown/Tan Port 13/RX 26 26
60 Pink/Violet
Violet/Pink
Port 6/TX 11 11
45 Tan/Pink
Pink/Tan Port 14/TX 27 27
61 Pink/Blue
Blue/Pink
Port 6/RX 12 12
46 Tan/Orange
Orange/Tan Port 14/RX 28 28
62 Pink/Yellow
Yellow/Pink
Port 7/TX 13 13
47 Tan/Violet
Violet/Tan Port 15/TX 29 29
63 Pink/Green
Green/Pink
Port 7/RX 14 14
48 Tan/Blue
Blue/Tan Port 15/RX 30 30
64 Pink/Gray
Gray/Pink
Port 8/TX 15 15
49 Tan/Yellow
Yellow/Tan Port 16/TX 31 31
65 Orange/Violet
Violet/Orange
Port 8/RX 16 16
50 Tan/Green
Green/Tan Port 16/RX 32 32
66 Orange/Blue
Violet/Blue
—
33
67
NOT USED —
34
68
NOT USED
