Hardware overview 22
Model 3196RC T-DAC User Manual 1 • Introduction
CLK SOURCE Green On solid The 3196RC is set as the Master Clock source.
Flashing The 3196RC is set as the secondary clock source.
Off The 3196RC is set as the slave, getting its clock from the H.110 Bus.
CLK ERROR Yellow On solid Master Clock source has been lost and the 3196RC is using the secondary source
for its clock.
Flashing Master Clock source and the Secondary Clock source have been lost and the 3196RC
is using its internal crystal for its clock.
Off No clock errors currently detected.
TEST MODE Green On solid One or more iDSL ports or T1/E1 ports is in test mode.
Flashing One or more of the iDSL ports or the T1/E1 ports is in test mode and errors have
been received.
Off None of the iDSL ports is operating in test mode.
WAN a Green On solid Indicates the given port is activated, linked, and operating normally.
Single
Flash
Indicates that the Model 3196RC is detecting the network, but is unable to synchro-
nize with it.
Double
Flash
Indicates an error on any of the T1/E1 links.
Off Indicates no T1/E1 links are in use.
DSL
CONNECTION
(LEDs 1–16) Green On solid The port is activated, linked, and operating normally.
Flashing The port is activated but not linked or in an error state.
Off The iDSL port has not been configured to establish a link.
READY Blue On Card ready for removal from cPCI chassis.
Off Card not ready for removal from cPCI chassis.
a. The WAN LED provides status indications for the WAN links established via the T1/E1 ports on the rear blade
of the 3196RC.
Table 3. LED definitions (Continued)
LED Color Status Meaning
