Introduction 90
Model 3196RC T-DAC User Manual A • Network Ports (RJ-21X) connector pin-out
Port 15
15
40 Slate/Black
Black/Slate
Port 16
16
41 Blue/Yellow
Yellow/Blue
17
42 Orange/Yellow
Yellow/Orange
18
43 Green/Yellow
Yellow/Green
19
44 Brown/Yellow
Yellow/Brown
20
45 Slate/Yellow
Yellow/Slate
21
46 Blue/Violet
Violet/Blue
22
47 Orange/Violet
Violet/Orange
23
48 Green/Violet
Violet/Green
24
49 Brown/Violet
Violet/Brown
25
50 Slate/Violet
Violet/Slate
Table 9. Band Marked Color Code (Continued)
DSL Port 50 Pin Positions Wire Color Code
