Powerware 9330 - Manual (Page 244)

A---74 Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 REV. G 061502
DESCRIPTION:
DATE:
DRAWING NO: SHEET:
REVISION: G
164201300---19 1 of 1
051502
Dimensions are in millimeters and (inches)
REMOTE MONITOR PANEL DIMENSIONS
150
[5.9]
125
[4.9]
42
[1.65]
37.5
[1.5]
20
[0.79]
22.23
[0.875]
20
[0.79]
37.5
[1.5]
98.02
[3.9]
75
[2.95]
51.98
[2.05]
104.17
[4.1]
62.5
[2.5]
20.83
[0.82]
NOTE: Interface wiring and conduit between
the Remote Monitor Panel and the
UPS mounted Remote Monitor Card
are to be supplied by the customer.
CABLE EXIT
FOR
1/2” CONDUIT
(3 PLACES)
OPENINGS
4.75
[0.19]
MOUNTING
(6 PLACES)
X 12.7
[0.5]
SLOTS
NOTE: WILL MATCH
MOUNTING HOLES
ON A SINGLE OR
DOUBLE GANG
ELECTRICAL BOX.
