PHYSICAL FEATURES AND REQUIREMENTS
164201300---3
A---24 Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 REV. G 061502
1. The UPS equipment operating environment must meet the size and weight requirements
shown in Table AA, according to your UPS system configuration.
2. In the UPS system, the UPS, Options, and Battery cabinets are palleted separately for
shipping.
3. Do not tilt cabinets more than

10˚ during handling.
4. Dimensions are in millimeters (inches).
Table AA Equipment Weight Table AA. Equipment Weight
Component
Weight
Kg (lb)
Component
Shipping Installed Point Loading
UPS Cabinet with Filter and Batteries
Powerware 9330 (10 kVA---20 kVA)
461 (1017) 435 (958) 6 at 73 (160)
UPS Cabinet with Filter and Batteries
Powerware 9330 (25 kVA---40 kVA)
873 (1925) 838 (1847) 9 at 93 (205)
Options Cabinet with PDM and no transformer
Powerware 9330 (10 kVA---20 kVA)
118 (260) 90 (200) 4 at 23 (50)
Options Cabinet with PDM and 1 transformer
Powerware 9330 (10 kVA---20 kVA)
240 (530) 213 (470) 4 at 53 (118)
Options Cabinet with PDM and 2 transformers
Powerware 9330 (10 kVA---20 kVA)
358 (790) 331 (730) 4 at 83 (183)
Options Cabinet with PDM and no transformer
Powerware 9330 (25 kVA---40 kVA)
154 (340) 120 (265) 6 at 20 (44)
Options Cabinet with PDM and 1 transformer
Powerware 9330 (25 kVA---40 kVA)
471 (1040) 437 (965) 6 at 73 (161)
Options Cabinet with PDM and 2 transformers
Powerware 9330 (25 kVA---40 kVA)
782 (1725) 748 (1650) 6 at 125 (275)
Battery Cabinet 361 (795) 333 (735) 6 at 56 (123)
NOTES:
Powerware 9330 (10 kVA---20 kVA)
1. For UPS Cabinet without Filter, subtract 25 Kg (55 lb).
2. For UPS Cabinet without Batteries, subtract 227 Kg (499 lb)
3. For Options Cabinet without PDM, subtract 11 Kg (25 lb)
Powerware 9330 (25 kVA---40 kVA)
1. For UPS Cabinet without Filter, subtract 41 Kg (90 lb).
2. For UPS Cabinet without Batteries, subtract 453 Kg (998 lb)
3. For Options Cabinet without PDM, subtract 11 Kg (25 lb)
5. The clearances required around the UPS System are shown in Table AB.
Table AB. System Clearances
From Front of Cabinet
36 inches working space
From Back of Cabinet 12 inches air circulation clearance
From Sides of Cabinet Allow space for Options and Battery Cabinets
