Ups cabinet power terminals, Left view – Powerware 9330 User Manual
Page 218
A---48
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 REV. G 061502
DESCRIPTION:
DATE:
DRAWING NO:
SHEET:
REVISION: D
3 of 6
053001
UPS CABINET POWER TERMINALS
LOCATION OF UPS CABINET TERMINALS
LEFT VIEW
164201300---9
POWERWARE 9330 (25 kVA--40 kVA)
INPUT
BREAKER CB1
AC INPUT TO UPS
RECTIFIER (CB1)
(DUAL INPUT)
(A, B, C)
AC INPUT TO BYPASS
(TB2)
(DUAL INPUT)
(A, B, C, N)
AC OUTPUT TO
CRITICAL LOAD (TB3)
(A, B, C, N)
AC INPUT TO UPS RECTIFIER
AND BYPASS (TB2)
(SINGLE INPUT)
(A, B, C, N)
WIREWAY
POWER WIRING
REMOTE
BATTERY
INPUT
