50

J693

Step

Operator Action

Displayed Message

Comment

11


Using the Gain Number
data collected from Steps 9
and 10, subtract each Label
Value from the TOF Value.
From the resulting list of
Difference Values, select
the largest number. Its
associated Gain Number is
the best selection for the
media. See the example
from below.


" "

]<<<_

JQQ

HQ L RVI

-OR-

"

]<<<_

JQQ

HQ L RVI


‘yyy’ is a
numerical value
representing the
current sensor
reading.


Both sensor
readings must
be above 20.


Gain Number

Label Value

TOF Value

Difference Value

00

255

254

1

01

251

240

11

02

241

213

28

03

231

182

49

04

219

150

69

05

212

119

93

06

200

88

112

07

189

58

131

08

178

32

146

09

167

20

147

10

156

17

139

11

146

16

130

12

136

15

121

13

126

15

111

14

116

14

102

15

112

14

98

Example from the data compiled in the table above: Gain Algorithm
Number 8 should be used because it has the highest difference value
(146) where both the Label Value and the TOF Value is above 20.

(Continued next page)
