Peration, Operating modes – Powerware 5140 User Manual
Page 39
Operation
31
Powerware
®
5140 User’s Guide
:
www.powerware.com
C H A P T E R
4
O
PERATION
This chapter covers the operation of the UPS, including:
: Operating modes
: UPS shutdown
: Starting the UPS on battery
: Maintenance bypass
Operating Modes
The Powerware 5140’s front panel indicates the UPS status through the
LCD panel and the UPS indicators.
Menu Controls
LCD Panel
UPS Indicators
Test Button
On Button
Off Button
Figure 22. Front Panel Operational Controls
