Powerware 5140 User Manual
Page 27
Installation
19
Powerware
®
5140 User’s Guide
:
www.powerware.com
NOTE Steps 2 through 4 are for EBM installation only. If you do not have optional
EBMs, skip to Step 5 on page 21.
2. Remove the EBM connector cover on the UPS. If a second EBM
is to be used, remove the EBM connector cover on the first EBM
(see Figure 5).
For each EBM connector cover, remove and retain the cover
screw. Discard the cover.
UPS Rear Panel
EBM Rear Panel
Figure 5. Removing the EBM Connector Covers
