62 Cajun M770 ATM Switch Manager User’s Guide
Slot Number The slot number in which the module is located. Slots
are numbered from left to right, starting with number
1 as the leftmost slot.
This number may be 1 - 14. The agent module is
inserted in either slot 15 or 16. A module which
occupies two enclosure slots, will be identified by the
number of the second slot (the right-hand slot). The
slot number is the position in which the module is
located. There can be up to 5 modules in a device.
The Slot Number is set using the rotary switch on the
back panel of the device.
Slot/Port The slot number and port number where the VC
(Virtual Channel) starts/terminates. Port 0 is the CPU
port.
State The state of the summary address indicates whether
or not it is advertised.
•
Advertising - This summary is being advertised.
• Suppressed - This summary is not being
advertised.
• Inactive - No addresses fall under this summary.
State Unchanged for The amount of time measured in days, hours,
minutes, and seconds, that the LEC’s state regarding
the LES has not changed. For more information, refer
to Current State on page 51.
Status Resilient status and link status of the selected LES.
Summary Address Summary of ATM addresses that are connected to this
node. The Summary Addresses may be advertised
throughout the PNNI domain.
Suppress The state of summary address advertising. Possible
states are:
•
on - The summary is not advertised, and all
addresses that fall under this summary are not
known in the PNNI domain.
• off - The summary is advertised.
Field Name Description
