Chapter 7 Managing LANE Services
36 Cajun M770 ATM Switch Manager User’s Guide
For a full description of the fields in the Registered LESs on ELAN window, refer to
Appendix B, Configuration Fields.
Configuring the LES/BUS Table
The LES/BUS Table contains a list of all of the LESs configured on a module. In the
LES/BUS Table dialog box you can view, add, and edit the LESs situated on this
module.
A Cajun M770 ATM module can provide up to 16 combined LES/BUSes.
To configure the LES/BUS Table:
1 Select the module you want to manage.
2 Open the Configuration menu and select LANE LES/BUS Table . The LES/BUS
Table is displayed.
Figure 7.6 LES/BUS Table
The LES/BUS Table provides information on the LESs that are configured on the
selected module, such as the LESs name, type, status, and registration mode.
Adding LESs
To add LESs to the LES/BUS Table:
1 Click Add . The LES/BUS Table expands to enable editing.
