Cajun M770 ATM Switch Manager User’s Guide 57
Manual, LES at address The address of the LES. This field is only significant
if the discovery method of the LES is set to Manual.
For more information, refer to Discovery on page 52.
Max Number of Slots Maximum number of ATM Switch modules that can
work together as a single switch within the device.
Maximum Active LESs (1-
10) The maximum number of LESs that can be
configured for the ELAN.
Module Type The module type.
Name if Known The name of the LEC that has been assigned by the
user. The name can be assigned using the Lucent
Name Server.
Neighbor IP The IP address of the immediate neighbor switch that
the VC passed through or of the end station where the
VC terminates.
Node ATM Address The ATM address of the PNNI node. This may be
important when the node acts as a PNNI border node
and/or a PNNI Peer Group Leader.
Node Oper Status The operational status of the PNNI node.
nrt-VBR Admin Weight The administrative weight given to the nrt-VBR
(non-realtime-Variable Bit Rate) class of service, when
determining the cost of a link.
Number of Configured
VCs The number of virtual channels that are currently
configured.
Number of Ports The number of ports located on the module.
Number of Virtual Ports The number of virtual ports on the physical port.
Oper Status Operational status of the port or VC (Virtual Channel).
Possible statuses are up and down.
Field Name Description
