Cajun M770 ATM Switch Manager User’s Guide 39
Chapter 8
Managing Routing
This chapter explains the routing options of the Cajun M770 ATM Switch. It includes
the following sections:
• Managing the static routes table
• Managing PNNI (Private Network-Network Interface)
Managing the Static Routes Table
The Static Routes Table provides information about all routes in the Cajun M770 ATM
Switch database.
In the Static Routes Table you can:
• View the ports associated with an ATM address.
• View the origin of the routing entry.
• Update the routing table.
Viewing the Static Routes table
To view the Static Routes Table:
1 Click .
OR
Open the Configuration menu and select Static Routes . The Static Routes Table
appears.
Figure 8.1 Static Routes Table
The Static Routes Table provides information on static routes, such as port, address
prefix, origin, and status.
