56 Cajun M770 ATM Switch Manager User’s Guide
LES Registration Type The LES registration mode to be supported by the
LECS. Possible modes are:
•
Prop LANE autosense - The LECS will adopt
the proprietary registration version from the first
registering LES.
• Prop LANE resilient - The LECS will only
allow a LES using the proprietary registration
method which supports resilient LESs.
• Prop LANE distributed - The LECS will only
allow a LES using the proprietary registration
method which supports distributed LESs.
LES Required State The required state of the LES. Possible states are:
• up
• down
Local at switch address
with Selector A one byte Selector appended to the module’s 19 byte
ATM address, to form the address advertised by the
selected LECS.
Local at WKA A LECS is created on this module and it will advertise
the WKA.
Local LECS Mode Selects whether the LECS will be resilient.
Local LECS Resilient
Priority The priority level of the LECS. The default priority is
128. A priority of 255 ensures that it is always elected.
A priority of 0 ensures that it is never elected.
Local LECS Status The operational status of the local LECS. Possible
statuses are:
•
Resilient Active
• Resilient Standby
• Not Resilient.
This field will be blank if the LECS location is
remote.
MAC Address The MAC address of the device, agent, or ring
interface.
Field Name Description
