Cajun M770 ATM Switch Manager User’s Guide 61
Required State The required state of the LES. Possible states are:
• up
• down
Root Virtual Port - SVC
VCI range VCI values allowed for use on this Root Virtual Port.
rt-VBR Admin Weight The administrative weight given to the rt-VBR
(realtime-Variable Bit Rate) class of service, when
determining the cost of a link.
Rx Cell discards Number of cell discards on hardware elements of the
module since the last reset.
S/W Version The version of the application software running on
the module or agent.
Scrambling Enables or disables payload scrambling. To enable
payload scrambling for a port, select the Scrambling
check box. By default, payload scrambling for a port is
disabled.
Serial Number A unique number assigned by Lucent Technologies
to the selected hardware.
Shape Port Speed Maximum speed of data transfer allowed on this port.
Signalling Status The status of the signaling process at an ATM port.
Possible values are: up, down.
Slot The slot number where the selected M770 ATM
module is installed.
Field Name Description
