Chapter 3 ATM Switch Configuration
Cajun M770 ATM Switch Manager User’s Guide 17
Viewing Neighbor Information
The Neighbor Information window provides information on the neighbor device
connected to the port. If the attached device is a UNI device, only ILMI information is
displayed.
To view neighbor information:
1 Open the Cajun M770 ATM Zoom View and select a port.
2 Open the Configuration menu and select Port Neighbor Info .
OR
Right-click a port and select Neighbor Info . The Neighbor Info window is
displayed.
Figure 3.5 Neighbor Information
The Neighbor Info window provides information about the neighbor device connected
to the port such as its name and addresses.
Note: ILMI information is displayed only if ILMI is enabled.
If the neighbor device is a PNNI device, you can view its PNNI information by
expanding the Neighbor Info window. To expand the Neighbor Info window:
1 Click Neighbor PNNI Info . The Neighbor PNNI Info window is displayed.
