50 Cajun M770 ATM Switch Manager User’s Guide
Call Use The type of VC (Virtual Channel):
•
PVC - Permanent VC
• SVC - Switched VC
Configuration Symbol For Module Configuration: The version of the
module. The version is updated whenever there is a
functional modification to the module.
For Agent Configuration: The version of the hardware
and firmware of the agent.
Configured ATM prefix The configured ATM address prefix of the Cajun
M770 ATM Device. When the switch is reset, this
becomes the Current ATM Address.
Configured ELAN Name The name of the ELAN that the management LEC
expects to join when it next leaves and re-enters the
network. This information is sent to the LECS, which
uses it to determine the ELAN that the management
LEC should join. If you do not specify an ELAN
name, the management LEC will join the default
ELAN of the type that you specify.
Configured ILMI Status The configured state of the ILMI protocol stack.
Configured Node Id The identifier of the node within the PNNI domain.
Ensure that the Node ID is unique within the
domain.
Configured Node Level The PNNI hierarchy level in which the node resides.
Configured Node Peer
Group Id The Peer Group ID in which the node resides.
Configured Signalling
Type The configured type of signalling to be used by the
root virtual port.
Configured Termination
Type The configured UNI termination on the root virtual
port.
CrossConnected Id Index of the VC in the Cross Connect table.
Current ATM prefix The current ATM prefix of the Cajun M770 ATM
Device.
Field Name Description
