Cajun M770 ATM Switch Manager User’s Guide 49
Appendix B
Configuration Fields
Field Name Description
Address The ATM address of the port.
Address Format The ATM address that the LECS will advertise.
Possible values are:
•
WKA - A Well Known Address.
• Selector - Selector means the module address plus
a selector byte.
Address Suppress The state of summary address advertising. Possible
states are:
•
on - The summary is not advertised, and all
addresses that fall under this summary are not
known in the PNNI domain.
• off - The summary is advertised.
Address Type The type of RAs the summary applies to. Possible
types are:
•
Internal - The summary applies to Reachable
Addresses within the PNNI domain.
• Exterior - The summary applies to Reachable
Addresses that are outside the PNNI domain.
Admin Status The administration status of the Physical Port, Root
Virtual Port, or Virtual Channel.
Agent Slot Number The number of the slot holding the Master Agent.
Agent SW Version The version of the application software running on
the module or agent.
Agent Type The agent type.
ATM Address The ATM address of the selected port, agent, LEC,
or Neighbor device.
BUS Address The BUS ATM address for the selected LES.
