Konica Minolta 7235 - Manual (Page 124)

5-12. LDAP Configuration
115
II Network Setup - Administrators only
Chapter 5 Web Utility
3
Enter the following items.
„ Enable LDAP
„ LDAP Server Address
„ LDAP Server Port Number
„ Enable SSL
„ Search Root
„ Connection Timeout
„ Maximum Hit Number
„ Authentication Type
„ Dynamic Authentication
„ User Name
„ Password
„ Domain Name
4
Input the password and click the [Apply] button.
This password is a key operator password.
Clicking [Clear] aborts all settings input up to this point.
5
Input the password and click the [Check LDAP Setting] button.
This password is a key operator password.
When the settings are entered correctly, a message confirming a successful connection is displayed.
When the connection has failed, check the settings for each item and re-enter the data.
● Changes do not take effect until you start the copier. Be sure to wait at least 10 seconds after turning off
the main power switch before you turn the copier back on.
