W-2WAY ECO-i SYSTEM Unit Specifications
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
4. Concealed Duct Type (U Type)
Indoor unit (B)
MODEL No. UHX1252
Power source 208 - 230 V / 1ø / 60 Hz
Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor)
Fan...(Number diameter / length in. (mm)) Centrifugal (1 ... ш7-31/64 (ш190))
Fan motor
Model...Nominal output W SFG4X-51C6P...50W
Power source 208 - 230 V / 1ø / 60 Hz
No. of pole...r.p.m. (230V, High) rpm 4P... 834
Coil resistance
(Ambient temperature 68°F)
Ω
BRN – WHT : 86.0 ORG – YEL : 15.9
WHT – VLT : 13.4 YEL – BLK : 30.1
VLT – ORG : 23.4 BLK – PNK : 27.5
Run capacitor VAC, µF 450 VAC, 1.5 µF
Safety device fuse
Operating temperature
Open °F (°C) 266 ± 9 (130 ± 5)
Close °F (°C) 181 ± 27 (83 ± 15)
Electronic expansion valve
Coil UKV-U031E
Coil resistance (at 68°F) Ω
ORG – GRY : 46 YEL – GRY : 46
RED – GRY : 46 BLK – GRY : 46
Valve body UKV-18D31
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows...fin pitch in. (mm) 2...1 / 16 (1.5)
Face area ft 2 (m 2 ) 1.22 (0.113)
Drain pump PLD-12230ST
Rated V, Hz, W AC230V, 60Hz, 10.8W
Total head & capacity
in. (mm), gal/
min (cc/min)
19-11 / 16 (500), 0.11 (400)
