W-2WAY ECO-i SYSTEM Unit Specifications
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1. Outdoor Unit
SPW-C0705DXHN8
SPW-C0905DXHN8
SPW-C1155DXHN8
SPW-C1305DXHN8
SPW-C1405DXHN8
MODEL
Position of center
of gravity(mm) Weight
(kg) X Y Z
390 450 774 245
332 481 697 295
374 486 654 345
Top view
Right side
Front view
CHDX09053
CHDX14053
MODEL
Position of center
of gravity(In.) Weight
(lbs) X Y Z
13-5/64 18-15/16 27-7/16 650
14-23/32 19-9/64 25-3/4 761
35-3/64 (T
op panel dimension
)
37-13/32 (Max.)
74 - 19/6
4
65 - 25/3
2
(8-1/2)
31-19/64
36-7/32 (Installation hole pitch)
31-7/64 (Installation hole pitch)
35-3/64 (Top panel dimension)
1-47/64
31-7/64
34-9/16
Position of center
of gravity
