W-2WAY ECO-i SYSTEM Unit Specifications
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1. Outdoor Unit
Unit Specifications (2)
MODEL NAME W-2WAY ECO-i Capacity Control Outdoor Unit <16 horsepower>
MODEL No. CHDX14053
POWER SOURCE 208-230V/3ø/60Hz
PERFORMANCE
Cooling capacity BTU / h (kW) 153,600 (45.0)
Heating capacity BTU / h (kW) 170,600 (50.0)
UNIT DIMENSIONS
Height in. (mm) 74-9/32 (1887)
Width in. (mm) 35-1/32 (890)
Depth in. (mm)
Ceiling dimension : 35-1/32 ~ +2-3/8
(890 ~ +60)
Net weight lbs. (kg) 760 (345)
Color (Munsell code) Silky shade (1Y 8.5 / 0.5)
ELECTRICAL RATINGS
Voltage rating V 208 230
Cooling
Running amperes A 46.6 44.8
Power input kW 13.3 13.3
Power factor % 79 75
Heating
Running amperes A 52.4 49.2
Power input kW 13.2 13.2
Power factor % 70 67
Starting amperes A 172 162
COMPRESSOR
Type - Q'ty Hermetic type x 3
Motor output kW 3 + 4.5 x 2
Refrigeration oil
Type FV68S (Ether oil)
Charge amount gal 1.56
Crankcase heater W 25 + 32 x 2
Capacity control % –
Refrigerant amount at shipment lbs. (kg) R410A - 28.7 (13.0)
Refrigerant control Electronic expansion valve
Defrost method Reverse-cycle defrost, outdoor unit cycle defrost
Heat exchanger Aluminum plate fin / Copper tube
FAN DEVICE
Type - Q'ty Propeller fan x 1
Air circulation CFM 7,770
External static pressure in.WG 0
Motor output (No. of poles) kW 0.7/8P
Protective devices High pressure switch, overcurrent (CT method)
TUBING
Refrigerant tubing
Gas tube in. (mm) ш1-1/8 (ш28.58) (Brazing)
Liquid tube in. (mm) ш1/2 (ш12.7) (Flare nut)
Balance tube in. (mm) ш1/4 (ш6.35) (Flare nut)
Drain port –
External air temperature operation range °F Cooling: 14 ~ 109 °F (DB) Heating: -4 ~ 59 (WB)
Operation sound (Hi) dB-A 62.0 (Quiet mode: 59.0)
Primary accessories
Connection tubing
ш1-1/8 (ш28.58)
* Performance, electrical characteristics values and operating sound are based on JIS B8616 package A/C.
(Colling : Indoor intake air temperature 80°F DB / 67°F WB. Outdoor intake air temperature 95°F DB.)
(Heating : Indoor intake air temperature 70°F DB. Outdoor intake air temperature 47°F DB / 43°F WB.)
