Sanyo ECO R410A - Manual

85464369238000 ©SANYO 2009
– ECO-i System Air Conditioner –
Model Combinations
This air conditioner uses the new refrigerant R410A.
INSTALLATION INSTRUCTIONS
SANYO North America Corporation In Canada
Commercial Solutions Division SANYO Canada Inc.
2055 Sanyo Ave., San Diego
CA 92154, U.S.A. 201 Creditview Road, Woodbridge
Ontario, L4L 9T1, Canada
External diameter of service port R410A: 5/16"
NOTE
Indoor Units
Optional Controllers
RC
Timer Wired Remote Controller RCS-TM80BG
Wireless Remote Controller (For U, UM, D, F, FM Types) RCS-BH80AAB.WL
Wireless Remote Controller (For X Type) RCS-SH80AAB.WL
Wireless Remote Controller (For XM Type) RCS-XM18AAB.WL
Wireless Remote Controller (For A, T Types) RCS-TRP80AAB.WL
Wireless Remote Controller (For K Type) RCS-SH1AAB
Simplified Remote Controller RCS-KR1EG
System Controller SHA-KC64UG
Schedule Timer SHA-TM64AGB
Intelligent Controller SHA-KT256EA
Communication Adaptor SHA-KA128AAB
Remote Sensor ART-K45AGB
LonWorks Interface SHA-LN16UAB
Class 7 9 12 15 18 19 24 36 48 54
X
4-Way Air Discharge
Semi-Concealed
XHX1252 XHX1852 XHX2452 XHX3652
XM
4-Way Air Discharge
Mini Semi-Concealed
XMHX1252 XMHX1852
A
1-Way Air Discharge
Semi-Concealed
AHX0752 AHX0952 AHX1252
U Concealed Duct Type UHX0762 UHX0962 UHX1262 UHX1562 UHX1862 UHX2462 UHX3662 UHX4862 UHX5462
UM
Slim Concealed
Duct Type
UMHX0762 UMHX0962 UMHX1262 UMHX1562 UMHX1862
D
Concealed-Duct High
Static Pressure
DHX3652 DHX4852
T Ceiling-Mounted THX1252 THX1852 THX2452
K Wall-Mounted Type KHX0752 KHX0952 KHX1252 KHX1862 KHX1962 KHX2452
F Floor-Standing Type FHX0762 FHX0962 FHX1262 FHX1562 FHX1862 FHX2462
FM
Concealed-Floor
Standing Type
FMHX0762 FMHX0962 FMHX1262 FMHX1562 FMHX1862 FMHX2462
