User’s Manual
DVR-4TN/8TN/16TN/16TS/16TT Series
SPECO TECHNOLOGIES 01/08
96
5.6.7 Per Channel Config
This menu is used to set the Video Loss Detect, Motion Detect and Alarm In /
Out function for each channel. The menu is displayed as below.
Per Channel Config
1. Channel Select
2. Video Loss Detect
3. Motion Detect
4. Detection Config
5. Alarm In
6. Alarm Out
7. Digital Deterrent CH1
OFF
OFF
OFF
None
OFF
5.6.7.1 Channel Select
This item is used to select a desired channel for setting the parameters. Move
the cursor to and press ENTER, then select a channel
using UP / DOWN keys. Press ENTER again to confirm the setting.
5.6.7.2 Video Loss Detect
This item allows the user to enable / disable Video Loss as an alarm event.
Select to enable Video Loss alarm events, to disable. The
default setting is .
5.6.7.3 Motion Detect
To detect motions, the users can choose from these options: , ,
, , , ,
, and . The Day, Night, and Weekend is defined in section 3.6.2
Schedule Setup or 5.4.2 Schedule Setup.
If motion detection function is enabled, it is required to define the motion
detection parameters such as detection area and sensitivity settings.
