User’s Manual
DVR-4TN/8TN/16TN/16TS/16TT Series
SPECO TECHNOLOGIES 01/08
86
Record Setup
1. Record Mode
2. Schedule Setup
3. Preset Config
4. Per Camera Config
5. ezRecord Setup
6. Data Lifetime
7. Pre-Alarm Recording
8. Circular Recording
9. Audio Recording
10. Purge Data
720×240@60PPS
Standard
0 Days
15 Sec
ON
ON
5.4.1 Record Mode
This item is for you to preset the resolution and recording rate of normal
record and event record. The relative record settings, such as duration, will
follow the record mode setting. The offered options are <720×480@30PPS>,
<720×240@60PPS>, <360×240@120PPS>, <720×480@30JPG>,
<720×240@60JPG> and <360×240@120JPG> in NTSC
(<720×576@25PPS>, <720×288@50PPS>, <360×288@100PPS>,
<720×576@25JPG>, <720×288@50JPG>, <360×288@100JPG> in PAL).
NOTE: If you choose the item with “PPS” as the last 3 letters, then you
choose to record in MPEG-4 compression; if you choose the item with
“JPG” as the last 3 letters, then you choose to record in MJPEG
compression.
Move the cursor to this item and press ENTER, then select a Record mode
using UP / DOWN keys.
NOTE: After changing the Record Mode setting, the warning message
“This will FORMAT ALL HARD DISKS and LOAD THE FACTORY
DEFAULT CONFIG!” will be shown on the screen. Press ENTER to
confirm the selection, then the unit will start to format the hard disks
and load the factory default settings, or press ESC to abort.
We strongly recommend backing up your programmed configuration
before making any changes on Record Mode settings.
