User’s Manual
DVR-4TN/8TN/16TN/16TS/16TT Series
SPECO TECHNOLOGIES 01/08 89
5.4.4.2 Normal PPS
Normal PPS (Picture per Second) is used to set the recording rate for normal
status.
Please note that the total normal pps for all channels is limited under the
maximum PPS for each Record mode. To increase one channel’s pps, you
may have to reduce other’s first. Event pps is not restricted to this rule, since a
smart event scheduler will handle the total pps automatically.
5.4.4.3 Normal Qlty
This item is used to set the picture size for normal status recording. The
available options are listed as follow: , , , and
.
5.4.4.4 Event Max PPS
Event Max PPS is used to set the event recording rate for Event status.
Normally, the Event PPS is set to be equal to or greater than Normal PPS; the
setting depends on your application. If the Event PPS is set to <0>, the
DVR-4TN/ 8TN/ 16TN/ 16TS/ 16TT series unit stops recording event video
during alarms.
5.4.4.5 Event Qlty
This item is used to set the picture size for event status recording. Refer to
section 5.4.4.3 Normal Qlty for the available options.
5.4.4.6 Event Active
Users are allowed to choose which alarm type needs to be recorded. The
available options are (alarm events), (motion detection
events), (alarm event + motion detection), and (no events
active). The default setting is , which includes Alarm and Motion event
recording.
5.4.5 ezRecord Setup
This item aims to avoid the complicated record settings and to make the setup
much easier. Note that this item can be reached only when you select
as the option for . For more information, please
refer to the
Appendix J: ezRecord Diagram Sample .
