Sundance Technology ST201 PRELIMINARY draft 2
PIN DESCRIPTIONS
PIN NAME PIN TYPE PIN DESCRIPTION
PCI INTERFACE
RSTN INPUT Reset, asserted LOW. RSTN will cause the ST201 to reset all of its
functional blocks. RSTN must be asserted for a minimum duration of
10 PCICLK cycles.
PCICLK INPUT PCI Bus Clock. This clock is used to drive the PCI bus interfaces and
the internal DMA logic. All bus signals are sampled on the rising edges
of PCICLK. PCICLK can operate from 0MHz to 33MHz.
GNTN INPUT PCI Bus Grant, asserted LOW. GNTN signals access to the PCI bus
has been granted to ST201.
IDSEL INPUT Initialization Device Select. The IDSEL is used to select the ST201 dur-
ing configuration read and write transactions.
INTAN OUTPUT Interrupt Request, asserted LOW. The ST201 asserts INTAN to
request an interrupt, when any one of the programmed interrupt event
occurs.
WAKE OUTPUT Wake Event, assertion level is programmable (see I/O Registers sec-
tion, WakeEvent bit 3). The ST201 asserts WAKE to signal the detec-
tion of a wake event.
REQN OUTPUT Request, asserted LOW. The ST201 asserts REQN to request PCI bus
master operation.
AD[31..0] IN/OUT PCI Bus Address/Data. Address and data are multiplexed on the AD
pins. The AD pins carry the physical address during the first clock cycle
of a transaction, and carry data during the subsequent clock cycles.
CBEN[3..0] IN/OUT PCI Bus Command/Byte Enable, asserted LOW. Bus command and
byte enables are multiplexed on the CBEN pins. CBEN specify the bus
command during the address phase transaction, and carry byte
enables during the data phase.
PAR IN/OUT Parity. PCI Bus parity is even across AD[31..0] and CBEN[3..0]. The
ST201 generates PAR during address and write data phases as a bus
master, and during read data phase as a target. It checks for correct
PAR during read data phase as bus master, during every address
phase as a bus slave, and during write data phases as a target.
FRAMEN IN/OUT PCI Bus Cycle Frame, asserted LOW. FRAMEN is an indication of a
transaction. It is asserted at the beginning of the address phase of the
bus transaction and de-asserted before the final transfer of the data
phase of the transaction.
IRDYN IN/OUT Initiator Ready, asserted LOW. A bus master asserts IRDYN to indi-
cate valid data phases on AD[31..0] during write data phases, indicates
it is ready to accept data during read data phases. A target will monitor
IRDYN.
TABLE 2: ST201 Pin Descriptions
