Sundance Technology ST201 PRELIMINARY draft 2
PIN TYPE OD6 (OPEN DRAIN OUTPUT BUFFER)
V
OL
Output low voltage I
OL
= 6mA 0.4 V
I
OZ
Output leakage current V
IN
= V
DD
/V
SS
-10 10 µA
PIN TYPE OD8 (OPEN DRAIN OUTPUT BUFFER)
V
OL
Output low voltage I
OL
= 8mA 0.4 V
I
OZ
Output leakage current V
IN
= V
DD
/V
SS
-10 10 µA
PIN TYPE PINS
PCI INTERFACE
IT RSTN, PCICLK, GNTN, IDSEL
IT/OP3 AD[31:0], CBEN[3:0], PAR
ITU/OP6 FRAMEN, IRDYN, TRDYN, DEVSELN, STOPN, PERRN
OD6 INTAN, PMEN, SERRN
OP3 REQN
EXPANSIONROM INTERFACE
ITU/OT4 ED[7:5], ED[3:0]
ITD/OT4 ED[4]
OT4 EWEN, EOEN, EA[15:0]
EEPROM INTERFACE
IT EEDO
OT4 EEDI, EESK, EECS
MII INTERFACE
IT TXCLK, CRS, COL, RXER, RXDV, RXD[3:0], RXCLK
IT PHYLNKN, PHYSPDN, PHYDPLXN
OT4 TXD[3:0], TXEN, MDC
IT/OT4 MDIO
TABLE 5: Pin Type Assignment
PARAMETER
SYMBOL
PARAMETER
DESCRIPTION
TEST CONDITIONS MIN MAX UNIT
TABLE 4: DC Characteristics
