Sundance Technology
ST201
PRELIMINARY draft 2
OCTETSTRANSMITTEDOK
Class....................I/O Registers, Statistics
Base Address ......IoBaseAddress register value
Address Offset .....0x6c
Access Mode .......Read (also clears register)/Write
Width ...................32 bits
BIT
BIT NAME
BIT DESCRIPTION
19..0
OctetsTransmitte-
dOk
This statistic counts the total number of frame header, data and pad-
ding octets in frames that are successfully transmitted. This is a 20-bit
counter and will wrap around to zero after reaching fffffh. An Updat-
eStats interrupt will occur after the counter has counted through
c0000h. This statistic must be read as two 16-bit quantity with the
lower word first. Upon reading the lower word, the upper word value is
latched in and the lower value is cleared. The upper word is also
cleared when read.
31..20
Reserved
Reserved for future use. Should be set to 0.
