Sundance Technology ST201 PRELIMINARY draft 2
DC CHARACTERISTICS
DC characteristics are defined over commercial operating ranges unless specified otherwise.
PARAMETER
SYMBOL
PARAMETER
DESCRIPTION
TEST CONDITIONS MIN MAX UNIT
PIN TYPE IT (TTL, PCI INPUT BUFFER)
V
IH
Input high voltage 2 V
V
IL
Input low voltage 0.8 V
I
IN
Input leakage current V
IN
= V
DD
/V
SS
-10 10 µA
PIN TYPE ITU (TTL, PCI INPUT BUFFER WITH PULL UP)
V
IH
Input high voltage 2 V
V
IL
Input low voltage 0.8 V
I
IN
Input leakage current V
IN
= V
DD
/V
SS
-10 10 µA
PIN TYPE ITD (TTL, PCI INPUT BUFFER WITH PULL DOWN)
V
IH
Input high voltage 2 V
V
IL
Input low voltage 0.8 V
I
IN
Input leakage current V
IN
= V
DD
/V
SS
-10 10 µA
PIN TYPE OT4/OC4 (TTL, CMOS OUTPUT BUFFER)
V
OH
Output high voltage I
OH
= -4mA 2.4 V
V
OL
Output low voltage I
OL
= 4mA 0.4 V
I
OZ
Output leakage current V
IN
= V
DD
/V
SS
-10 10 µA
PIN TYPE OP3 (PCI OUTPUT BUFFER)
V
OH
Output high voltage I
OH
= -2mA 2.4 V
V
OL
Output low voltage I
OL
= 3mA 0.55 V
I
OZ
Output leakage current V
IN
= V
DD
/V
SS
-10 10 µA
PIN TYPE OP6 (PCI OUTPUT BUFFER FOR PCI I/O WITH PULL UP)
V
OH
Output high voltage I
OH
= -2mA 2.4 V
V
OL
Output low voltage I
OL
= 6mA 0.55 V
I
OZ
Output leakage current V
IN
= V
DD
/V
SS
-10 10 µA
TABLE 4: DC Characteristics
