Chapter 2 Locations and Functions of Parts and Controls
2-27
2
2-5 Setup Menu Operating
Section
Setup menu operating section
1 Setup card compartment
Open the cover and insert the BSC-1 Setup Card (not supplied) into the
slot with the “SONY” logo facing you, then close the lid.
2 Rotary encoder
When the cursor is aligned with the page title of a setup menu, pressing
the rotary encoder changes to the page switching mode. When the cursor
is other than on the page title, pressing the rotary encoder switches to the
mode in which you can change the value of the current menu setting.
To change the page or vary a setting value, turn the rotary encoder.
3 MENU ON/OFF/PAGE (menu display/paging) switch
This switch is used to display the setup menu on the viewfinder screen or
the test signal screen and to page through the menu items. When you
close the cover, this switch is automatically set to OFF.
1
2
3 4
