Chapter 5 Setting Up the Camcorder

5-38

5

Bottom view

Shoulder pad

5-8 Adjusting the Shoulder

Pad Position

You can shift the shoulder pad from its center position backward or
forward by up to 10 mm (3/8 inch). This adjustment helps you get the
best balance for shooting with the camcorder on your shoulder.

Adjusting the shoulder pad position

1

Loosen the two screws.

2

Slide the shoulder pad backward or forward until it is in the most
convenient position.

3

Tighten the screws.

1,3

2
