Chapter 6 Maintenance
6-11
6
1
Detach the eyepiece unit from the viewfinder.
For more information, see Section 5-2-4 “Detaching the Eyepiece” (page
5-15).
2
Remove the eyecup from the eyecup holder.
3
Remove the protecting filter together with the packing ring from
inside the eyecup holder.
4
Detach the protecting filter from the packing ring.
Fog-proof filter
Depending on the temperature and humidity, the protecting filter may
mist because of vapor or your breath. To ensure that the viewfinder is
always clear, replace the protecting filter with a fog-proof filter (Part No.
1-547-341-11, not supplied).
Fitting the fog-proof filter
Detach the protecting filter from the packing ring, and replace it with the
fog-proof filter.
Be sure to correctly assemble the fog-proof filter, the packing ring, and
the eyecup so that the reassembled eyepiece is waterproof.
Note
When cleaning the fog-proof filter, wipe it very gently with a soft cloth
to avoid impairing the anti-fogging coating.
