Chapter 5 Setting Up the Camcorder

5-20

5

Connect to the MIC IN
connector.

Set the AUDIO IN switch for the
desired recording channel to FRONT.

5-5 Audio Input System

5-5-1 Using the Supplied Microphone

You can use the supplied microphone either detached from or attached to
the camcorder.

Using the microphone detached from the camcorder

Using the microphone detached from the camcorder

Note

When using the supplied microphone with an extension cable, always
use an external power supply type cable.
