Chapter 4 Adjustments and Settings for Recording
4-26
4
Off
These bars go on.
These bars go on.
Excessive input level
Normal input level
Corresponding peak value
4
Use the MONITOR switch to select the channel whose audio level
is indicated in the viewfinder.
CH1: Audio level of CH-1
CH2: Audio level of CH-2
MIX: Mixed audio level of CH-1 and CH-2
5
Turn the MIC AUDIO LEVEL control on the front of the camcorder
to adjust the audio level while seeing the audio level indication on
the window screen.
• When the incoming audio level is normal, the nine bars from the
bottom are on.
• The second bar from the top may turn on occasionally, but do not
allow the top bar to go on. If it goes on, the audio level is too high.
40
30
10
0
•
20
