Chapter 4 Adjustments and Settings for Recording
4-25
4
(Continued)
Adjusting the audio level of the microphone
You can adjust the audio level input from the microphone for channels 1
and 2 by using the MIC AUDIO LEVEL control on the front of the
camcorder.
Microphone audio level adjustment
1
Set either or both AUDIO IN switches to FRONT as follows:
• When using the front microphone input for both channels 1 and 2:
Set both AUDIO IN switches to FRONT.
• When using the front microphone input for either channel 1 or 2:
Set the AUDIO IN switch for the desired channel to FRONT.
2
Set the AUDIO SELECT switch(es) for the desired channel(s) to
MANUAL.
3
Set the DISPLAY switch at the viewfinder to ON.
The audio level indication of the channel 1 will appear in the
viewfinder.
1
2
5
3
4
