Appendix
A-7
A
GENLOCK IN (BNC type)
1.0 Vp-p, 75 ohms
TC IN (BNC type)
0.5 V to 18 Vp-p, 10 kilohms
Signal outputs
VIDEO OUT (BNC type)
1.0 Vp-p, 75 ohms, unbalanced
TEST OUT (BNC type)
1.0 Vp-p, 75 ohms, unbalanced
AUDIO OUT (XLR, 5-pin, male)
0 dBm
TC OUT (BNC type)
1.0 Vp-p, 75 ohms
EARPHONE (minijack)
8 ohms,
−∞
to
−
18 dBu (or
−
18 dBs) variable
Others
DC IN (XLR, 4-pin, male)
11 to 17 V DC
DC OUT (4-pin)
11 to 17 V DC, maximum current 0.1 A
LENS (12-pin)
REMOTE (8-pin)
