MAINTENANCE
Remove the vent plug (A) shown in the picture, the oil level must
be with line on the dipstick. If it is below line on the dipstick add oil.
Use oil type EP 320 in the following quantity:
- Mower with 5 discs (AGM52) 4,20 l
- Mower with 6 discs (AGM62) 5,20 l
- Mower with 7 discs (AGM72) 6,20 l
- Mower with 8 discs (AGM82) 7,20 l
M
A
IN
T
EN
A
N
C
E
Lubrication of gearbox
In order to check oil level, stop the machine and be sure it is set in horizontal position.
Use oil type
EP 320
. Gearbox capacity is around 0,70 l.
Change the oil in the gearbox
after the first 10/15 hours of work.
Then replace oil
every 500 hours of work
and at least once a year. When the mower is used for a long period, check
oil level on a daily basis and add oil if necessary.
Check oil level with the dipstick on the vent plug
AGM 52-62-72-82 10/10 Maintenance Section 5-5
