OPERATION
Check Lifting and Stable Operation of the Tractor
For lifting and stable operation of the tractor refer to the following formula. Additional tractor front ballast may be
needed.
Z
M
s i d
0,2 T
T
M X s < 0,2 T X i + Z (d + i)
M < 0,3 T
i =
Wheelbase tractor
d =
Distance between front axle and ballast
s =
Distance to the rear axle of the machine
T =
mass of the tractor + 75 kg (operator)
Z =
Mass of ballast
M =
Mass of the machine
O
PER
A
T
IO
N
Check lifting and stable operation of the tractor in order to avoid upset and/or loss of
adherence to the road.
AGM 52-62-72-82 10/10 Operation Section 4-9
