65
• You can adjust the crossover frequency within the range of
50 ~ 200 Hz.
• Select "FULL" when the selected speaker can fully
reproduce the low frequencies below 50 Hz.
When selecting the Crossover Frequency
■Note :
• You cannot select the subwoofer and the speakers set to
"No".
• Only when the Trinnov Position is set to "None", you can set the Crossover Frequency manually. (For details, refer to "When
selecting the Trinnov Position" on page 72.)
• Set the crossover frequency according to the frequency characteristics of the speakers connected.
(For details on the frequency characteristics, refer to the operating instructions of the speakers.)
• If the frequency range of your speaker is 100 Hz ~ 20 kHz, the crossover frequency should be set to 100 Hz (or slightly higher).
• The low frequencies below the crossover frequency are to output from subwoofer or the speakers which are set to "Full" (when
not using a subwoofer).
1.
Press the CURSOR UP(
▲)/DOWN(▼) buttons to select the Crossover Frequency, then press the ENTER
button.
2.
Press the CURSOR UP(
▲)/DOWN(▼) buttons to select the desired speaker.
3.
Press the CURSOR LEFT(
◀)/RIGHT(▶) buttons to set the crossover frequency as desired.
4.
Repeat the above steps 2 and 3 until the crossover frequencies are all set as desired.
