Adjusting the current channel level

• Each time these buttons are pressed, the corresponding

channel is selected as follows:

( ): Possible depending on whether the surround back

channel is set to "2 ch" or "1 ch".

< >: Possible only when the digital signals from Dolby

Digital or DTS sources, etc. that include LFE signal
are input.

• Depending on the speaker settings("No", etc.) and

surround mode, etc., some channels cannot be
selected.

• When the SPEAKER button is set to off, only the Front

Left, Front Right (and LFE) channels can be selected.

• After adjusting each channel level with test tone, adjust the channel levels either according to the program sources or to suit

your tastes.

• You can adjust the current channel levels as desired. These adjusted levels are just memorized into user’s memory

("TRIM"), not into preset memory("REF 1", "REF 2").

■

Note :

• Only when the Trinnov Position is set to "None", you can adjust the channel levels, memorize and recall them.

(For details, refer to "When selecting the Trinnov Position" on page 72.)

• The LFE level can be adjusted within the range of -10 ~

0 dB and other channel levels within the range of -15 ~
+15 dB.

• In general, we recommend the LFE level to be adjusted

to 0 dB.(However, the recommended LFE level for
some early DTS software is -10 dB.) If the
recommended levels seem too high, lower the setting
as necessary.

• Then the memory mode ("TRIM" or "REF 1", etc) is

displayed for several seconds.

• When the memory mode or channel level disappears,

press this button again.

Press the CHANNEL LEVEL button.

Adjust the level of the selected channel as

desired.

Repeat the above steps 2 and 3 to adjust each

channel level.

Select the desired channel.
