Remote Control Functions
3. Timer Remote Controller (RCS-TM80BG)
0000 Not displayed
(The optimal setting for that model was set at the time of shipment.)
0001 150 hours
0002 2,500 hours
0003 5,000 hours
0004 10,000 hours
Filter sign ON time
(filter lifetime)
0005 Use the filter clogging sensor.
0001 Central control address 1
0002 Central control address 2
0003 Central control address 3
0064 Central control address 64
Central control address
0099 No central control address set (setting at time of shipment)
Compressor ON Compressor OFF
0000 MED 1 min., LO 3 min. LO
O L D E M 1 0 0 0
O L O L 2 0 0 0
0004 MED 1 min., LO 3 min. MED
D E M D E M 5 0 0 0
Fan speed when
heating thermostat is
OFF
D E M O L 6 0 0 0
0000 No shift
0001 Shifts intake temperature 2°F ( 1°C ) down.
0002 Shifts intake temperature 4°F ( 2°C ) down.
0003 Shifts intake temperature 6°F ( 3°C ) down.
0004 Shifts intake temperature 8°F ( 4°C ) down.
0005 Shifts intake temperature 10°F ( 5°C ) down.
Heating intake
temperature shift
0006 Shifts intake temperature 12°F ( 6°C ) down.
0000 Normal (Setting at time of shipment)
Cooling-only
0001 Cooling only
• In order to avoid water leakage and damage to the fan, do not set for humidifying when the thermostat is OFF
unless a vaporizing humidifier is used.
• Consider the device purpose and type when changing the settings. Incorrect settings may result in malfunction.
• Do not change any setting data that does not appear in this list.
List of Simple Setting Items
NOTE
All settings except for the system address, indoor unit
address, and group address were set at the time of
shipment. The following procedures are necessary
only when the functions are changed.
The functions cannot be changed in the case of a
wireless remote controller or a system with no remote
controller.
Change the functions using the wired remote con-
troller (RCS-TM80BG).
Sets items which are highly important for system
operation, such as the system address, indoor unit
address, and group address, at the individual or
group-control indoor unit(s) where the remote con-
troller that is used for making detailed settings is con-
nected.
These settings are for items that are extremely
important for system operation. Serious trouble
may occur if they are set incorrectly. Please use
sufficient caution when changing the settings.
Some item codes which do not appear in the list
are also displayed. These item codes were set at
the time of shipment from the factory to the opti-
mal settings for that model; do not change them.
Do not change any settings data which does not
appear in this list.
(Perform these steps with the unit stopped.)
Press and hold the (TEST/CHK) button, the
(SET) button and (CANCEL) button
simultaneously for 4 seconds or longer. Check
that the (SETTING) display on the remote
controller begins to blink.
If group control is in effect, press the
(UNIT SELECT) button and select the address
(unit No.) of the indoor unit to set. At this time, the
indoor unit fan begins operating.
Press the temperature setting /
buttons to select the item code to change.
3
2
1
CAUTION
Press the timer time / buttons to select
the desired setting data.
* For item codes and setting data, refer to the fol-
lowing page.
Press the (SET) button. The (SETTING)
display stops blinking and remains lit, and setting is
completed. (If the (SET) button is not pressed,
the settings data will not be changed.)
Repeat steps (2) – (5) and change the settings.
Press the (TEST/CHK) button. Check that the
remote controller display disappears.
7
6
5
4
7
2
1 5 4
3
