Specifications
Designs & specifications are subject to change without notice.
TO BE CONTINUED ON THE NEXT PAGE
Amplifier
Output Power
At Stereo operation:
Front channels:
60 W per channel, min. RMS, both channels driven
into 8
Ω at 1 kHz with no more than 0.9% total
harmonic distortion. (IEC268-3/DIN)
At Surround operation:
Front channels:
60 W per channel, min. RMS, driven into 8
Ω at
1 kHz with no more than 0.8% total harmonic
distortion.
Center channel:
60 W, min. RMS, driven into 8
Ω at 1 kHz, with no
more than 0.8% total harmonic distortion.
Rear channels:
60 W per channel, min. RMS, driven into 8
Ω at
1 kHz, with no more than 0.8% total harmonic
distortion.
Audio
Audio Input Sensitivity/Impedance (1 kHz):
DVD, STB, VCR, TV, TAPE:
220 mV/47 k
Ω
Audio Input (DIGITAL IN)* :
Coaxial:
DIGITAL 1 (DVD):
0.5 V(p-p)/75
Ω
Optical:
DIGITAL 2 (STB):
–21 dBm to –15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround
(with sampling frequency—32 kHz, 44.1 kHz, 48 kHz).
Audio Output Level:
VCR, TV, TAPE:
220 mV
Signal-to-Noise Ratio (’66 IHF/DIN):
DVD, STB, VCR, TV, TAPE:
87 dB/62 dB
Frequency Response (8
Ω):
DVD, STB, VCR, TV, TAPE:
20 Hz to 20 kHz (±1 dB)
Tone Control:
Bass (100 Hz):
±10 dB
Treble (10 kHz):
±10 dB
Bass Boost:
+6 dB ± 1 dB at 70 Hz
Video
Video Input Sensitivity/Impedance (1 kHz):
Composite video:
DVD, STB, VCR, TV: 1 V(p-p)/75
Ω
S-VIDEO:
DVD, STB, VCR:
(Y:luminance):
1 V(p-p)/75
Ω
(C:chrominance): 0.286 V(p-p)/75
Ω
RGB:
DVD, STB, VCR:
0.7 V(p-p)/75
Ω
Video Output Level/Impedance (1 kHz):
Composite video:
VCR, TV:
1 V(p-p)/75
Ω
S-VIDEO:
TV:
(Y:luminance):
1 V(p-p)/75
Ω
(C:chrominance): 0.286 V(p-p)/75
Ω
RGB:
TV:
0.7 V(p-p)/75
Ω
Signal-to-Noise Ratio (S/N):
45 dB
Synchronize:
Negative
