Cabling I/O Modules
ERX Edge Routers
4-15
Warning: IEC 825, Class 1 laser fiber connectors are for connection only to
Class 1 laser devices.
1 Insert the TX male fiber connector into the selected port.
2
Terminate the other end in the appropriate network connection.
3
Repeat steps 1 and 2 for the RX fiber connector.
4
Repeat steps 1–3 for the remaining ports.
Figure 4-9 I/O module with SC full duplex connectors
Cabling SMB Connectors
To cable I/O modules with SMB connectors:
1
Pull back the metal sheath on the TX cable’s SMB connector.
2 Insert the TX cable’s SMB connector into the selected port.
3 Release the metal sheath on the TX cable’s SMB connector.
SINGLE
MODE
OC3
I/O
Port 0
Port 1
TX
RX
Fiber
TX
RX
TX
RX
