Connection Information
ERX Edge Routers
B-19
SRP
(5 Gbps)
b
SRP-5G SRP I/O 7 • Terminal blocks
• BNC
• Wire wrap posts
• RJ-45
• RS-232 (DB-9)
See Chapter 4, Cabling the ERX
System .
SRP (5 Gbps) SRP-5G+ SRP I/O 7 • Terminal blocks
• BNC
• Wire wrap posts
• RJ-45
• RS-232 (DB-9)
See Chapter 4, Cabling the ERX
System .
SRP
(10 Gbps) SRP-10G SRP I/O 7 • Terminal blocks
• BNC
• 75 ohm
• Wire wrap posts
• RJ-45
• RS-232 (DB-9)
See Chapter 4, Cabling the ERX
System .
SRP
(40 Gbps)
b
SRP-40G SRP I/O 7 • Terminal blocks
• BNC
• 75 ohm
• Wire wrap posts
• RJ-45
• RS-232 (DB-9)
See Chapter 4, Cabling the ERX
System .
SRP
(40 Gbps) SRP-40G+ SRP I/O 7 • Terminal blocks
• BNC
• 75 ohm
• Wire wrap posts
• RJ-45
• RS-232 (DB-9)
See Chapter 4, Cabling the ERX
System .
Table B-3 Connection information for module assemblies (continued)
Assembly
Name and
Capability Line
Module
Label
I/O Module
Label No. of
Ports
Connector Type Cabling Specifications
